ENME 414 Computer Aided Design

Fall 1999

Homework 6 Assembly II

Due Friday, October 15. 1999

Components: 2 Medium 305W Radial Bearings

A gear component (You specify the required tolerances)

A special nut for fastening the gear component (You design the detail)

A shaft (You specify the required tolerances)
